M Union

Union coupling with female press fitting for stainless steel pipe and male thread, Figure 341. Made of A-316L stainless steel in accordance with EN 14404, with EPDM/FKM O-rings and threaded in accordance with DIN 2999. The union withstands a maximum pressure of 16 bar at 90°C and 6 bar at 180°C. It withstands a temperature range from -20 to 110°C with EPDM seal and from -20 to 180°C with FKM seal. The union, model 01341, complies with the requirements of UNE-EN-10088, as well as DVGW GW534-2004 and DVGW GW541:2004-10. It is suitable for use in domestic water, heating, fire-fighting and compressed air (oil-free) if fitted with an EPDM O-ring and for oils, hydrocarbons (except diesel), solar installations and compressed air if fitted with an FKM seal. MT Press stainless steel press fittings are suitable for pipes that comply with DVGW GW541 and UNE-EN-10088. MT Industrial Division products are high-quality stainless steel parts, specifically designed for industrial contexts. The entire range is manufactured under strict quality parameters and complies with the highest certifications in fluid handling.

ReferenceMeasuresWeight (KG)Small / Large box
0134101510Male union stainless steel mt-press ø 15x3/8”0.0410 / 160
0134101515Male union stainless steel mt-press ø 15x1/2”0.0510 / 160
0134101520Male union stainless steel mt-press ø 15x3/4”0.0810 / 160
0134101815Male union stainless steel mt-press ø 18x1/2”0.0610 / 120
0134101820Male union stainless steel mt-press ø 18x3/4”0.0810 / 120
0134102215Male union stainless steel mt-press ø 22x1/2”0.0710 / 100
0134102220Male union stainless steel mt-press ø 22x3/4”0.110 / 100
0134102225Male union stainless steel mt-press ø 22x1”0.1210 / 80
0134102820Male union stainless steel mt-press ø 28x3/4”0.1110 / 60
0134102825Male union stainless steel mt-press ø 28x1”0.1310 / 60
0134102832Male union stainless steel mt-press ø 28x11/4”0.1710 / 50
0134103525Male union stainless steel mt-press ø 35x1”0.165 / 100
0134103532Male union stainless steel mt-press ø 35x11/4”0.175 / 100
0134103540Male union stainless steel mt-press ø 35x11/2”0.215 / 100
0134104232Male union stainless steel mt-press ø 42x11/4”0.195 / 50
0134104240Male union stainless steel mt-press ø 42x11/2”0.235 / 50
0134105440Male union stainless steel mt-press ø 54x11/2”0.315 / 30
0134105450Male union stainless steel mt-press ø 54x2”0.365 / 30
0134107665Male union stainless steel mt-press ø 76x21/2”0.671 / 8
0134108100Male union stainless steel mt-press ø 108x4”0.91 / 3
0134108880Male union stainless steel mt-press ø 88x3”1.411 / 7
