Hose Nipple

Series 87 hose nipple with threaded connection. Reinforced body made of yellow brass and union threads in accordance with ISO 228/1. Nipple 87315 is designed to join valves or other fittings. Operating temperature range from -20 to 150°C for figures without seals and from -20 to 100°C for figures with seals. MT’s threaded brass fittings are manufactured in accordance with the hot stamping method and in accordance with EN 1254-4. They are quick and easy to install, saving time and facilitating assembly. They have a high temperature resistance, which makes them ideal for fluid handling applications in cold water, hot water and compressed air, and are suitable for copper and plastic pipe systems (PE, PEX, PP, Pb).

Manufactured in accordance with EN 1254-1 Designed for use with EN 1057:1966 copper pipes
ReferenceMeasuresWeight (KG)Small / Large box
8731500810BRASS THREADED HEXAGON HOSE NIPPLE 1/4"X10MM0.0210 / 600
8731500812BRASS THREADED HEXAGON HOSE NIPPLE 1/4"X12MM0.0210 / 500
8731501012BRASS THREADED HEXAGON HOSE NIPPLE 3/8"X12MM0.0310 / 300
8731501512BRASS THREADED HEXAGON HOSE NIPPLE 1/2"X12MM0.0410 / 300
8731501514BRASS THREADED HEXAGON HOSE NIPPLE 1/2"X14MM0.0510 / 280
8731501516BRASS THREADED HEXAGON HOSE NIPPLE 1/2"X16MM0.0510 / 240
8731501518BRASS THREADED HEXAGON HOSE NIPPLE 1/2"X18MM0.0510 / 230
8731501520BRASS THREADED HEXAGON HOSE NIPPLE 1/2"X20MM0.0610 / 190
8731502020BRASS THREADED HEXAGON HOSE NIPPLE 3/4"X2MM0.0710 / 140
8731502025BRASS THREADED HEXAGON HOSE NIPPLE 3/4"X25MM0.0810 / 120
8731502525BRASS THREADED HEXAGON HOSE NIPPLE 1"X25MM0.115 / 100
8731502530BRASS THREADED HEXAGON HOSE NIPPLE 1"X30MM0.125 / 80
8731503230BRASS THREADED HEXAGON HOSE NIPPLE 11/4"X30MM0.165 / 50
8731503235BRASS THREADED HEXAGON HOSE NIPPLE 1 1/4"X35MM0.195 / 50
8731503238BRASS THREADED HEXAGON HOSE NIPPLE 11/4"X38MM0.185 / 40
8731503240BRASS THREADED HEXAGON HOSE NIPPLE 1 1/4"X40MM0.225 / 40
8731504038BRASS THREADED HEXAGON HOSE NIPPLE 1 1/2"X38MM0.235 / 30
8731504045BRASS THREADED HEXAGON HOSE NIPPLE 1 1/2"X45MM0.285 / 30
8731504050BRASS THREADED HEXAGON HOSE NIPPLE 1 1/2"X5MM0.345 / 20
8731505060BRASS THREADED HEXAGON HOSE NIPPLE 2"X6MM0.511 / 33
